Product Introduction ::
 The Rotary Encoder LED Ring has thru-hole or shaft mounting for most standard encoders and uses a Texas Instruments TLC5925 shift register to interface 16 blue + 16 red LEDs to any microcontroller through SPI.  A microcontroller can be programmed to output any desired sequence on the LEDs.


Applications ::
Audio Balance Level
eg. ADC value

Specification ::
Power consumption requierment  DC4.5/5.5V 250mA max
16x LEDs , Blue+Red Color
Smart Rotary Encoder
Switch for LEDs Role
SPI Mode


Documents / Demo ::


Arduino Code : http://dlnmh9ip6v2uc.cloudfront.net/datasheets/Components/Switches/Rotary_Encoder_LED_Ring_Example.pde
Schematics    : http://dlnmh9ip6v2uc.cloudfront.net/datasheets/Components/Switches/Rotary%20Encoder%20LED%20Ring%20Schematic.pdf

Write a review

Your Name

Your Review

Note: HTML is not translated!

Rating Bad Good

Rotary Encoder LED Ring Breakout Board ( Blue + Red - Two Color )

Brand: Others
Product Code: RO925
Reward Points: 20
Availability: 30

$20.99
Price in reward points: 20
